Description
The Warn G2 winches are often used as an industrial winch, trailer winch and for tow trucks and recovery vehicles.
G2 DC electric winches are ideal for first responders, commercial vehicles and other applications where an electric winch is preferred. New levels of performance, durability and efficiency help get the job done quickly and reliably time after time. In addition to 12V, this series is also available in 24V and there is also a hydraulic version on the market.
| G2 9 | G2 12 | G2 15 | |
|---|---|---|---|
| Part number | 104320 (anti-clockwise) 104325 (clockwise) | 104420 (anti-clockwise) 104425 (clockwise) | 104520 (anti-clockwise) 104525 (clockwise) |
| Rated Line Pull | 4080kg | 5443kg | 6800kg |
| Motor | 12V DC | 12V DC | 12V DC |
| Gear | 3-Stage planetary | 3-Stage planetary | 3-Stage planetary |
| Brake | Disc brake | Disc brake | Disc brake |
| Remote | |||
| Winch line (not included) | Wire cable 12.7mm x 23m | Wire cable 12.7mm x 23m | Wire cable 12.7mm x 23m |
| Fairlead (not included) | Roller fairlead (ø30.5cm) | Roller fairlead (ø30.5cm) | Roller fairlead (ø30.5cm) |
| Measurements WxDxH | 668.8mm x 214mm x 283.46mm | 668.8mm x 214mm x 283.46mm | 668.8mm x 214mm x 283.46mm |
| Bolt patten WxD | 304.8mm x 165.1mm | 304.8mm x 165.1mm | 304.8mm x 165.1mm |
| Weight (without winch line) | |||
| Line speed no load/load | 7.9MPM / 1.7MPM | 5.7MPM / 1.2MPM | 5.8MPM / 1.5MPM |
| Amp no load/load | 92.3AMP / 447AMP | 84.2AMP / 422.8AMP | 103.4AMP / 579.7AMP |
| Specification sheet | G2 9 sheet | G2 12 sheet | G2 15 sheet |
| Parts list |
The Warn G2 winches are often used as an industrial winch, trailer winch and for tow trucks and recovery vehicles. G2 DC electric winches are ideal for first responders, commercial vehicles and other applications where an electric winch is preferred. New levels of performance, durability and efficiency help get the job done quickly and reliably time after time. In addition to 12V, this series is also available in 24V and there is also a hydraulic version on the market.
| Part number |
| G2 9 – 104320 (anti-clockwise) / 104325 (clockwise) |
| G2 12 – 104420 (anti-clockwise) 104425 (clockwise) |
| G2 15 – 104520 (anti-clockwise) 104525 (clockwise) |
| Rated line pull |
| G2 9 – 4080kg |
| G2 12 – 5443kg |
| G2 15 – 6800kg |
| Motor |
| 12V DC |
| Gear |
| 3-Stage planetary |
| Brake |
| Disc brake |
| Remote |
| Winch line Wire cable (not included) |
| 12.7mm x 23m |
| Measurements WxDxH |
| 668.8mm x 214mm x 283.46mm |
| Bolt pattern |
| 304.8mm x 165.1mm |
| Weight (without winch line) |
| Line speed no load/load |
| G2 9 – 7.9MPM / 1.7MPM |
| G2 12 – 5.7MPM / 1.2MPM |
| G2 15 – 5.8MPM / 1.5MPM |
| Amps no load/load |
| G2 9 – 92.3AMP / 447AMP |
| G2 12 – 84.2AMP / 422.8AMP |
| G2 15 – 103.4AMP / 579.7AMP |
| Specification sheet |
| G2 9 sheet |
| G2 12 sheet |
| G2 15 sheet |
| Parts list |
