- 12V Electric Winch
- Pulling capacity: 4536kg
- Wire cable
- Corded remote control (3.7 m)
- Compact design
Warn ZEON XC 10 | 12V | Wire cable | 110410
Binnenkort leverbaar!
Description
Warn ZEON XC 10 – Wire cable
“The power that works when everything is working against you”
The ZEON XC is a powerful and reliable winch that keeps working, even in the toughest conditions. It combines top performance with a compact, low-profile design, so it fits neatly on vehicles without taking up much space.
The winch is fast and built with durable, corrosion-resistant components of OEM quality. This ensures it remains dependable, even after intensive use.
The ZEON XC is flexible to install: the motor can be rotated 90 degrees and the control box can be relocated, allowing for various mounting options. The large aluminum drum reduces rope wear and helps dissipate heat. You can choose between a strong steel cable or a lightweight synthetic rope.
In addition, the winch features a powerful automatic brake for safe operation, durable black rust-resistant bolts, and a special aluminum fairlead for synthetic rope. In short: the ZEON XC is a fast, strong, and rugged winch you can rely on when you need it most.
| Specifications | ZEON XC 10 | ZEON XC 12 | ZEON XC 14 |
|---|---|---|---|
| Part number | Warn 110410 | Warn 110412 | Warn 110412 |
| Rated line pull | 4536kg | 5443kg | 6350kg |
| Motor | 12V DC | 12V DC | 12V DC |
| Gear | 3-Stage planetary | 3-Stage planetary | 3-Stage planetary |
| Brake | Conical | Conical | Conical |
| Remote Control | Wired 3.7m (wireless optional) | Wired 3.7m (wireless optional) | Wired 3.7m (wireless optional) |
| Wire Cable | 9.5mm x 24.4m | 9.5mm x 24.4m | 9.5mm x 24.4m |
| Fairlead | Roller (ø254mm) | Roller (ø254mm) | Roller (ø254mm) |
| Measurements LxWxH | 560.0mm x 171.1mm x 198.8mm | 560.0mm x 171.1mm x 198.8mm | 560.0mm x 171.1mm x 198.8mm |
| Bolt pattern LxW | 254mm x 114.3mm | 254mm x 114.3mm | 254mm x 114.3mm |
| Weight | 45kg | 45kg | 45kg |
| Line speed No load/load | 11.0MPM / 1.3MPM | 7.9MPM / 1.0MPM | 7.1MPM / 0.8MPM |
| Amps No load/load | 68AMP / 482AMP | 72AMP / 488AMP | 70AMP / 487AMP |
| Specifications |
| Part number |
| Warn 110410 |
| Rated line pull |
| 4536kg |
| Motor |
| 12v DC |
| Gear |
| 3-Stag planetary |
| Brake |
| Conical |
| Remote Control |
| Wires 3.7m (wireless optional) |
| Wire cable |
| 9.5mm x 30m |
| Fairlead |
| Roller (ø254mm) |
| Measurements LxWxH |
| 60.0mm x 171.1mm x 198.8mm |
| Bolt pattern LxW |
| 254mm x 14.3mm |
| Weight |
| 45kg |
| Line speed No load/load |
| 11.0MPM / 1.3MPM |
| Amps No load/load |
| 68AMP / 482AMP |
Additional information
| Weight | 40 kg |
|---|---|
| Dimensions | 70 × 60 × 40 cm |
