- 12V Electric Winch
- Pulling capacity 6350kg
- Synthetic winch rope
- Corded remote control (3.7 m)
- Wireless control via Hub (smartphone)
Warn ZEON XD 14 | 12V | Synthetic Rope | 110014
€4.405,61 incl. vat (21%)
In stock
In stock
Description
Warn ZEON XD 14 – Synthetic rope
“Redesigned and retooled from the ground up”
Designed and manufactured in Clackamas, Oregon, this winch boasts a new high-performance motor and geartrain, achieving impressive no-load line speeds of up to 12.2 m/min—the fastest in its class.
Its reliable waterproof construction, featuring O-ring rubber sealing, ensures durability with an IP68 submersion rating and IP69K high-pressure spray rating. The upgraded corrosion-resistant black fasteners and UV-resistant bus bar covers meet top-tier OEM specifications.
Full metal armor protects the internal components from impacts and damage, while the WARN Spydura synthetic rope is not only strong and lightweight but also easy to handle, featuring heat-resistant inner wraps and an abrasion sleeve for added protection.
The winch is equipped with a forged black aluminum fairlead that excels in corrosion, impact, salt, weather, and UV resistance, ensuring it maintains its good looks over time. For enhanced electrical reliability and efficiency, it incorporates Albright contactor control and bus bars.
Available in capacities of 4536 kg and 5443 kg, this winch is compatible with a variety of trucks, Jeeps, and SUVs. It comes with a durable waterproof corded remote featuring a 3.7-meter lead, plus the HUB receiver for over 30 meters of wireless control when paired with the WARN HUB app.
Backing this high-performance winch is an industry-leading warranty: a limited lifetime mechanical warranty and a seven-year electrical warranty, all supported by a global service network.
Specifications | ZEON XD 10-S | ZEON XD 12-S | ZEON XD 14-S |
---|---|---|---|
Part number | Warn 110010 | Warn 110012 | Warn 110014 |
Rated line pull | 4536kg | 5443kg | 6350kg |
Motor | 12V DC | 12V DC | 12V DC |
Gear | 3-Stage planetary | 3-Stage planetary | 3-Stage planetary |
Brake | Mechanical | Mechanical | Mechanical |
Remote Control | Wired 3.7m and wireless Hub (smartphone operated) | Wired 3.7m and wireless Hub (smartphone operated) | Wired 3.7m and wireless Hub (smartphone operated) |
Synthetic rope | 9.5mm x 30m Spydura | 9.5mm x 24.4m Spydura Pro | 9.5mm x 24.4m Spydura Pro |
Fairlead | Hawse fairlead (ø254mm) | Hawse fairlead (ø254mm) | Hawse fairlead (ø254mm) |
Measurements LxWxH | 606.7mm x 172mm x 267.2mm | 606.7mm x 172mm x 267.2mm | 606.7mm x 172mm x 267.2mm |
Bolt pattern LxW | 254mm x 114.3mm | 254mm x 114.3mm | 254mm x 114.3mm |
Weight | 32kg | 32kg | 32kg |
Line speed No load/load | 12.19MPM / 1.52MPM | 9.45MPM / 0.91MPM | 7.95MPM / 0.64MPM |
Amps No load/load | 64AMP / 458AMP | 67AMP / 466AMP | 65AMP / 482AMP |
View Alternative Products | View Warn ZEON XD 10 | View Warn ZEON XD 12 |
Specifications |
Part number |
Warn 110014 |
Rated line pull |
6350kg |
Motor |
12v DC |
Gear |
3-Stag planetary |
Brake |
Mechanical |
Remote Control |
Wires 3.7m and wireless Hub (smartphone operated) |
Synthetic rope |
9.5mm x 24.4m Spydura Pro |
Fairlead |
Hawse fairlead (ø254mm) |
Measurements LxWxH |
606.7mm x 172mm x 267.2mm |
Bolt pattern LxW |
254mm x 14.3mm |
Weight |
32kg |
Line speed No load/load |
7.95MPM / 0.64MPM |
Amps No load/load |
65AMP / 482AMP |
Additional information
Weight | 40 kg |
---|---|
Dimensions | 70 × 60 × 40 cm |
